Dining bar

Meeting room

Classroom

With FCT(Full Frequency Coherent Technology) technology

2" inch sound coil full-range driver

Low frequency response extend to 80Hz

Excellent vocal performance

Technical parameters

Frequency response

Nominal directivity(-6dB)

Sensitivity (@1w/1m)

Power Rating

Impedance

Maximum SPL

Transducers

100 Hz-18 kHz(±3 dB);

80 Hz-20 kHz(-10 dB)

80°（H）×80°（V）Constant directivity

94 dB

150 W

8 ohm

116 dB/126 dB SPL peak

1 x8" Full range driver

Power lnput

Connectors

Speaker Cables

Phoenix plug

1+1-

Physical Data

Dimensions(WxDxH)

Weight

Materials

Finish

Grille

Installation

Mesh

234x183x234 mm

9.8 kg

Imported multi-plywood Environmentalwaterproof and anti-corrosion coatings

Black polyurea paintings

Black Square Hole Stencil

Pole socket and for multiple flying points

DPR (Double perforation Rate) double perforation rate technology design, in which the perforation rate of the mid-high transmitting area is more than 90%, which greatly improves the sound transmission efficiency and reduces the acoustic crosstalk of the grille.
