F1600D

High power, multi-channel: F1600D, four channels

Features:

1、Supports 3 backups of analog/AES/Dante input signals

2、Network TCP/IP control, can realize the management of multiple  devices

3、Remote switch on/off

4、 Using 4.3-inch IPS capacitive touch screen

5、Built-in DSP digital processor, 48k/24bit

6、Support computer remote monitoring system, Ethernet network interface (RJ45); support a variety of online ways: USB, ICP, IP, RS232, RS485, and third-party GPIO open interface

7、Real-time remote monitoring of the amplifier's working status

8、Recognize the amplifier on site through software

9、Support bridge and matrix mode free switching

10、 Input sensitivity is adjustable in three steps 0dBu/6dBu/12dBu,  software or color  LCD setting

11、 Fir function is standard, supporting 4×2048 Taps

12、Constant voltage and constant resistance output  mode setting: 100V、70V、8Ω、4Ω

13、Software control, can simultaneously control the media matrix,  professional processor

14、Wide voltage operation 180-264VAC, energy-saving power supply  design, with power factor correction technology

15、With independent alarm function, fault or improper operation will  send out an alarm

16、With FINEAMP sound quality assurance

17、Comprehensive protection and early warning systems

18、With WVW wide voltage technology

Technical parameters:

four × 800W/8 Ω four channel

four × 1600W/4 Ω four channel

four × 2400W/2 Ω four channel

two × 3200W/8 Ω bridge stereo

two × 6000W/4 Ω bridge stereo

two × 8000W/2 Ω bridge stereo

two × 3200W 70V/100V constant voltage output

Frequency response (1W, 8 Ω): 20Hz-20kHz ± 0.5dB

THD+N: ≤0.05%(Ratedpower,4Ω/kHz)

IMD(1kHz, full power 4Ω): ≤0.05%

SNR(12dBu,1kHz): ≥95dB

Optional gain: 23,26,29,32,35,38,41,44dB

Cooling system: Airflow from front to back, Forced cooling

Input connectors: XLR

Input impedance: 4xSpeakon；Terminal block

Output connectors: USB/485

Power Input: 100-260V~47-63Hz

Dimensions: 483x377x88mm

Weight:14kg
