Type

Self- powered coaxial enclosure

Powering and driving system

Active

Bandwidth

50Hz - 22kHz ([FRONT] preset)

Maximum SPL

133dB ([FILL] preset)

Nominal directivity

Axisymmetric90°

Transducers

LF: 1 × 12’’, bass reflex

HF: 1 × 3’’compression

Rigging

Integrated pole mount socket, optional

ETR12-2 bracket and XTLIFTBAR accessory

Dimension(W×H×D)

410 x 540 x 390mm

16.1 x 21.3 x 15.4in

Net weight

32kg / 70.5lbs
